Máy điều trị nội nha ES-100 Meta Biomed

Endodontic Micro Motor
Advantages

• Powerful Performance with Long-lasting Battery

  – Stable Rotation: 250~800RPM (16:1)
  – Torque: 0.6~6.4 NCM
  – 10hrs of working time (2200mAh)
  – Swiss Micro Motor

• Ergonomically Designed Body with Small Headed, Durable, Chemically Resistant Contra-Angle

  – Remains intact after 1 week of immersion in Cavicide

• Torque Auto-Reverse, Auto Forward, Reciprocation

• Memory Functions

  – Memo 1 ~ 9
  – Memorizing RPM, Torque, Reverse Function, Rotation Direction

THÔNG SỐ/THÀNH PHẦN

• 1 Control Unit
• 1 Handpiece
• 1 Contra-Angle
• 1 AC Adapter

CONTROL UNIT

• TORQUE RANGE

  0.6~6.4Ncm (Gear Ratio 16:1)

• SPEED RANGE

  250~800rpm (Gear Ratio 16:1)

• RATED INPUT

  7.2V, 1.2A

• DIMENSIONS

  W110mm x D134mm x H116.5mm

• WEIGHT

  443g

• PROTECTION TYPE AND LEVEL AGAINST ELECTRIC SHOCK

  Type B applied part, Internally powered equipment

AC ADAPTER

• INPUT VOLTAGE

  100-240V~, 50Hz/60Hz

• OUTPUT VOLTAGE

  12V

• OUTPUT CURRENT

  1A

ĐẶC ĐIỂM CHÍNH

AUTO-REVERSE

When the preset torque is reached[1], the handpiece drive runs in an anti-clockwise direction[2], freeing the file. The drive then stops[3].

AUTO-FORWARD

When the preset torque is reached in Auto-Forward mode[1], the file automatically turns in the opposite direction[2], freeing the file, then continues rotating in a clockwise direction[3]

RECIPROCATION

Forward & reverse reciprocation
